Output	INA or INB	Gray
Operating Temperature Range	-10 to 70℃	-10 to 70℃
Rated Voltage	5V DC	12V DC
Maximum Operating Current	0.5mA	4mA
Resolution	12 or 24 pulses/360 ° endless	4 bit 16 pulses/360 ° endless
Insulation Resistance	10 M Ω　min.	10 M Ω　min
Detent position and angle	12 detents 30+/-3°or or 24 detents 15+/-3°	16 detents 22.5+/-3°
Torque	40 to 50 mN.m	40 to 50 mN.m
Life (cycles)	50,000 (INA) 100,000 (INB)	50,000
Dimensions	Dia. 16.0 x t = 6.5 mm	Dia. 16.0 x t = 6.5 mm

Application

Home appliances

Radio

Feature

• Heavy torque 40〜 50　Nm

• Incremental output

• INA, INB or Gray code outpu

• Choices of shaft shape & length

• Choice with and without detent
